BX Series Brushless DC (BLDC) Motor Speed Control Systems

Check up to five results to perform an action.


larger image

The BX Series brushless DC motor speed control system offers high performance and simple operation from a compact driver and motor. Combined with the optional OPX-1A control module, the BX Series can also provide excellent position control and torque control capabilities.

  • AC input
  • Frame sizes from 2.36 in to 4.33 in
  • Output power from 30 W (1/25 HP) to 400 W (1/2 HP)
  • Rated torque from 0.88 lb-in to 970 lb-in
  • Variable speed ranges from 0.015 ~ 15 r/min to 3 ~ 3000 r/min
  • Hollow shaft flat gearhead models available


Search Items



    Download PDF Download PDF
    border="0" Printable Page
    Email Email This Page
    Save To Favorites Save To Favorites

Request InformationCompare Items   Results Per Page :
  Results 1 - 25 of 592 Unit of Measure: Imperial | Metric  1 2 3 4 5 »

Item #

Motor Frame Size

Output Power

Power Supply

Shaft/Gear Type

Output Shaft Diameter

Rated Torque

Electromagnetic Brake

Variable Speed Range (r/min)

Web Price

BX230A-A 2.36 in. 30 W (1/25 HP) Single-Phase 100-115 VAC Round Shaft (No Gearhead) 8 mm 0.88 lb-in Not Equipped 30 ~ 3000 $589.05
BX230AM-A 2.36 in. 30 W (1/25 HP) Single-Phase 100-115 VAC Round Shaft (No Gearhead) 8 mm 0.88 lb-in Equipped 30 ~ 3000 $741.20
BX230C-A 2.36 in. 30 W (1/25 HP) Single-Phase/Three-Phase 200-230 VAC Round Shaft (No Gearhead) 8 mm 0.88 lb-in Not Equipped 30 ~ 3000 $609.45
BX230CM-A 2.36 in. 30 W (1/25 HP) Single-Phase/Three-Phase 200-230 VAC Round Shaft (No Gearhead) 8 mm 0.88 lb-in Equipped 30 ~ 3000 $761.60
BX460A-A 3.15 in. 60 W (1/12 HP) Single-Phase 100-115 VAC Round Shaft (No Gearhead) 10 mm 1.75 lb-in Not Equipped 30 ~ 3000 $619.65
BX460AM-A 3.15 in. 60 W (1/12 HP) Single-Phase 100-115 VAC Round Shaft (No Gearhead) 10 mm 1.75 lb-in Equipped 30 ~ 3000 $771.80
BX460C-A 3.15 in. 60 W (1/12 HP) Single-Phase/Three-Phase 200-230 VAC Round Shaft (No Gearhead) 10 mm 1.75 lb-in Not Equipped 30 ~ 3000 $640.05
BX460CM-A 3.15 in. 60 W (1/12 HP) Single-Phase/Three-Phase 200-230 VAC Round Shaft (No Gearhead) 10 mm 1.75 lb-in Equipped 30 ~ 3000 $792.20
BX5120A-A 3.54 in. 120 W (1/6 HP) Single-Phase 100-115 VAC Round Shaft (No Gearhead) 12 mm 3.50 lb-in Not Equipped 30 ~ 3000 $627.30
BX5120AM-A 3.54 in. 120 W (1/6 HP) Single-Phase 100-115 VAC Round Shaft (No Gearhead) 12 mm 3.50 lb-in Equipped 30 ~ 3000 $820.25
BX5120C-A 3.54 in. 120 W (1/6 HP) Single-Phase/Three-Phase 200-230 VAC Round Shaft (No Gearhead) 12 mm 3.50 lb-in Not Equipped 30 ~ 3000 $646.00
BX5120CM-A 3.54 in. 120 W (1/6 HP) Single-Phase/Three-Phase 200-230 VAC Round Shaft (No Gearhead) 12 mm 3.50 lb-in Equipped 30 ~ 3000 $838.95
BX6200A-A 4.09 in. 200 W (1/4 HP) Single-Phase 100-115 VAC Round Shaft (No Gearhead) 14 mm 5.8 lb-in Not Equipped 30 ~ 3000 $621.35
BX6200AM-A 4.09 in. 200 W (1/4 HP) Single-Phase 100-115 VAC Round Shaft (No Gearhead) 14 mm 5.8 lb-in Equipped 30 ~ 3000 $793.90
BX6200C-A 4.09 in. 200 W (1/4 HP) Single-Phase/Three-Phase 200-230 VAC Round Shaft (No Gearhead) 14 mm 5.8 lb-in Not Equipped 30 ~ 3000 $638.35
BX6200CM-A 4.09 in. 200 W (1/4 HP) Single-Phase/Three-Phase 200-230 VAC Round Shaft (No Gearhead) 14 mm 5.8 lb-in Equipped 30 ~ 3000 $810.90
BX6400S-A 4.09 in. 400 W (1/2 HP) Three-Phase 200-230 VAC Round Shaft (No Gearhead) 14 mm 11.50 lb-in Not Equipped 30 ~ 3000 $768.40
BX6400SM-A 4.09 in. 400 W (1/2 HP) Three-Phase 200-230 VAC Round Shaft (No Gearhead) 14 mm 11.50 lb-in Equipped 30 ~ 3000 $940.95
BX230A-A / OPX-1A 2.36 in. 30 W (1/25 HP) Single-Phase 100-115 VAC Round Shaft (No Gearhead) 8 mm 0.88 lb-in Not Equipped 3 ~ 3000 $828.05
BX230AM-A / OPX-1A 2.36 in. 30 W (1/25 HP) Single-Phase 100-115 VAC Round Shaft (No Gearhead) 8 mm 0.88 lb-in Equipped 3 ~ 3000 $980.20
BX230C-A / OPX-1A 2.36 in. 30 W (1/25 HP) Single-Phase/Three-Phase 200-230 VAC Round Shaft (No Gearhead) 8 mm 0.88 lb-in Not Equipped 3 ~ 3000 $848.45
BX230CM-A / OPX-1A 2.36 in. 30 W (1/25 HP) Single-Phase/Three-Phase 200-230 VAC Round Shaft (No Gearhead) 8 mm 0.88 lb-in Equipped 3 ~ 3000 $1,000.60
BX460A-A / OPX-1A 3.15 in. 60 W (1/12 HP) Single-Phase 100-115 VAC Round Shaft (No Gearhead) 10 mm 1.75 lb-in Not Equipped 3 ~ 3000 $858.65
BX460AM-A / OPX-1A 3.15 in. 60 W (1/12 HP) Single-Phase 100-115 VAC Round Shaft (No Gearhead) 10 mm 1.75 lb-in Equipped 3 ~ 3000 $1,010.80
BX460C-A / OPX-1A 3.15 in. 60 W (1/12 HP) Single-Phase/Three-Phase 200-230 VAC Round Shaft (No Gearhead) 10 mm 1.75 lb-in Not Equipped 3 ~ 3000 $879.05
  Results 1 - 25 of 592 1 2 3 4 5 »
